Characteristics：
This machine finishes the printing through the high precision mesh cylinder to convey the ink evenly to the printing cylinders which then directly print the ink by pressing on the tape surface. After that they are dried through the drying system. Then the whole printing is finished. It has 6 kinds of printing cylinders for the user to exchange. In this way, it changes the printing length, featuring accurate printing. It can print 60 meters per hour. It can be the substitute for the mesh printing machine.
Main Technical Variables:
|
Model
|
MHR1S
|
|
Front side printing
|
1colours
|
|
Back side printing
|
|
|
Max.Printing length
|
401mm
|
|
Min.Printinglength
|
108mm
|
|
Max.Printing width
|
150mm
|
|
Max. Printing speed
|
60m/min
|
|
Feeder/Rewinder capacity
|
400mm
|
|
Power
|
220V/2.75kw
|
|
Weight
|
342kg
|
|
Dimension(LxWxH)
|
1200*700*1500mm
|
|
